Different Types of Filter Cartridges
Cartridge filters are widely utilized across numerous industries, including water treatment, chemical processing, pharmaceuticals, and the food and beverage sector. Their widespread adoption is attributed to their ease of installation and maintenance, along with their high filtration efficiency.
These filters offer versatility and are available in various sizes, shapes, and materials tailored to specific requirements across different applications. Whether employed as a pre-filter to protect downstream equipment or as a final step to ensure product purity, cartridge filters play a pivotal role in diverse processes
Read on to learn more about cartridge filters and its various types, functionality and benefits.
What is a Cartridge Filter?
A cartridge filter serves as a crucial tool for eliminating impurities and particles from liquids or gasses. Its construction typically involves a cylindrical or pleated filter element encased within a housing made of diverse materials like paper, polyester, or cotton.
In the design process, establishing a specific micron rating is essential. This rating dictates the size of particles the filter can effectively capture. During operation, the fluid undergoing filtration is directed through the filter element. Here, impurities are trapped and retained, enabling only clean liquid or gas to pass through.
Types of Filter Cartridges
Cartridge filters encompass various types distinguished by their composition functionality, applications, and benefits.
- Wound Cartridge Filter:
Composition: Wound cartridge filters are crafted by winding a string around a central core, creating a multi-layered porous filter. Materials commonly used include cotton, fiberglass, or polypropylene.
Functionality: These filters operate on the principle of mechanical filtration, trapping contaminants within the winding pattern as fluid flows through. Their construction makes them suitable for applications that require high temperature or chemical resistance.
Applications: Wound cartridge filters find use in various industries for diverse applications, including water treatment, chemical processing, and oil filtration.
Benefits: The multi-layered design ensures efficient particle capture, while the winding pattern provides structural integrity and longevity that makes them a reliable choice for demanding filtration needs
- Melt Blown Cartridge Filter:
Composition: Melt blown cartridge filters consist of a fine polypropylene filter media, created by extruding and stretching molten polymer to form fibers.
Functionality: Operating on the principle of depth filtration, these filters trap contaminants within the depth of the filter media as fluid passes through. They are known for their high filtration efficiency and are effective in capturing fine particles.
Applications: Widely used across industries for their effective filtration capabilities, melt blown cartridge filters are commonly found in water treatment, food and beverage processing, and pharmaceutical applications.
Benefits: The fine polypropylene fibers offer excellent particle capture and the depth filtration mechanism removes contaminants thoroughly. Their versatility and efficiency make them suitable for a wide range of filtration tasks
- Air Cartridge Filter:
Composition:Air filter cartridge typically features a rigid frame and aluminum dividers, providing structural integrity. These components ensure the filters maintain their shape, even under challenging operating conditions.
Functionality:Designed to effectively filter air, these cartridges utilize their sturdy construction to withstand diverse environmental factors while efficiently capturing airborne contaminants.
Applications:Air filter cartridges are commonly employed in various industries and environments, including HVAC systems, industrial facilities, commercial buildings, and automotive applications. Their unique design makes them suitable for conditions where maintaining air quality is essential.
Benefits: The use of a rigid frame and aluminum dividers improves the durability and effectiveness of the air filter cartridge. By maintaining their shape and integrity, these filters optimize airflow and particle capture capability, prolonging the life of HVAC systems and equipment while promoting cleaner indoor air quality.
- Pleated Type Cartridge Filter:
Composition: Pleated cartridge filters feature a folded filter media that maximizes surface area for improved filtration. Materials used include polyester, cellulose, or PTFE.
Functionality: These filters improve filtration efficiency by increasing the available surface area for particle capture. They are commonly used in industrial water filtration and HVAC systems for efficient particle removal.
Applications: Pleated cartridge filters are deployed in various industries where prolonged service life and optimal flow rates are essential that contribute to clean and safe environments.
Benefits: The pleated design ensures efficient particle capture and extended service life, making them ideal for applications requiring high filtration performance.
- Sintered Cartridge Filter:
Composition:Sintered cartridge filters are manufactured by sintering metal particles to form a porous structure, typically made from stainless steel or bronze.
Functionality:These filters operate on the principle of depth filtration, with particles being trapped within the porous structure as fluid passes through. They offer high-temperature and chemical resistance.
Applications:Sintered cartridge filters are commonly used in industrial processes where efficient filtration capabilities are required that include oil and gas filtration, chemical processing, and pharmaceuticals.
Benefits: The sintered metal structure provides durability and resistance to high temperatures and corrosive environments that ensure reliable filtration performance in demanding applications.
- Wire Mesh Cartridge Filter:
Composition: Wire mesh cartridge filters are constructed from woven metal wires, typically stainless steel, arranged in a mesh pattern.
Functionality: These filters utilize the mesh structure to capture particles as fluid passes through. They offer versatility and durability, suitable for various filtration tasks.
Applications: Wire mesh cartridge filters find use in diverse industries, including automotive, aerospace, and water treatment, where efficient particle capture and durability are paramount.
Benefits: The woven wire mesh provides reliable particle capture and structural integrity, ensuring long-lasting performance in challenging environments.
Cartridge Filters vs Bag Filters
Bag filters are known for their extensive surface area and rapid flow rate that make them appropriate for scenarios with substantial quantities of coarse sediments. While they are relatively inexpensive, they may necessitate more frequent changes. Conversely, cartridge filters provide finer filtration and are durable, withstanding temperature variations and corrosive substances. They are well-suited for applications requiring high levels of purity, although they may have a slower flow rate compared to bag filters.
Below are the differences between cartridge filters and bag filters in detail:
| Feature |
Cartridge Filters |
Bag Filters |
| Application Preference |
Preferable for contaminations lower than 100 ppm (0.01% in weight) |
Frequently used for dust removal in industrial applications |
| Filter Type |
Surface or depth-type filters |
Mostly surface-type filters |
| Filtration Mechanism |
Depth-type filters capture particles through total thickness; surface filters block particles on the surface |
Particles captured on internal surface |
| Surface Area |
Limited surface area, depth-type filters have the advantage of depth |
Generally, higher surface area, offering higher flow rates, longer lifespan, and increased dirt holding capacity |
| Disposable or Cleanable |
Designed disposable; replaced when clogged |
Generally not designed for replacement when clogged; some can be cleaned, e.g., by mechanical shaking or backwashing with compressed air |
| Particle Concentration |
Suitable for concentrations lower than 100 ppm |
Surface filters favored for concentrations higher than 5 mg/m3; depth-type filters preferred for concentrations lower than 0.5 mg/m3 |
